LM HI-5/6/8/10

Download Download
  • Description
    • Commodity name: LM HI-5/6/8/10
    • 计费重量: 1

    The Efore three phase inverters series are designed for household energy storage. The power range is from 5kW to 10kW, compatible with high voltage(150-600V)batteries.

    Key Features

    Excellent performance
    -Maximum 15kW PV input power
    -Maximum battery charge/discharge current of 50A

    High Reliability
    -Multiple built-in protections

    Intelligence maintenance
    -Quick commission, remote monitoring, upgrade
    -Advanced energy management mechanism



    Technical Specifications

    Model LM HI-5 LM HI-6 LM HI-8 LM HI-10
    PV Input
    Max. DC Input Power (kW) 9 15
    Max. DC Input Voltage (V) 1000
    Start-up Voltage (V) 150
    MPPT Range (V) 160-950
    Max. Input Current (A) 15/15 20/30
    Max. Short Circuit Current (A) 20/20 30/40
    Number of MPPT 2
    No. of PV Strings Per MPPT 2(1/1) 3(1/2)
    Battery
    Battery Type Lithium-ion/Lead-acid
    Battery Voltage Range (V) 150-600
    Max.Charge/Discharge Current (A) 25/25 25/25 50/50 50/50
    Max.Charge/Discharge Power (W) 9000/5800 9000/7000 15000/9100 15000/11300
    AC Grid
    Rated AC Output Power (kW) 5 6 8 10
    Max. AC Output Power (kVA) 5.5 6.6 8.8 11
    Max. AC Output Power(PF=1) (kW) 5.5 6.6 8.8 11
    Max. AC Output Current (A) 3*8.3 3*10 3*13.3 3*16.7
    Max. Input Power (kW) 15
    Max. Input Current (A) 3*25
    Rated AC Voltage (V) Three Phase 380/400/415, 3W+N+PE
    AC Grid Frequency (Hz) 50/60
    Grid Frequency Range (Hz) 45-55/55-65(Adjustable)
    Power Factor >0.99 @ Rated Power(Adjustable 0.8 LD-0.8 LG)
    THDI <3%(Rated Power)
    AC Load Output
    Rated AC Output Power (kW) 5 6 8 10
    Rated AC Output Current (A) 3*7.6 3*9.1 3*12.2 3*15.2
    Peak Output Apparent Power(5min) (KVA) 6 7.2 9.6 12
    Peak Output Apparent Power(10s) (KVA) 7.5 9 12 15
    Rated AC Voltage (V) Three Phase 380/400/415, 3W+N+PE
    AC Frequency (Hz) 50/60
    Transfer Time (ms) <10
    THDV <3%@100% R Load
    Protection
    DC Switch Yes
    Anti-islanding Protection Yes
    AC Overcurrent Protection Yes
    DC/AC Overvoltage Protection DC Type II, AC type III
    AC Short Circuit Protection Yes
    DC Reverse Protection Yes
    Insulation Resistance Detection Yes
    Leakage Current Protection Yes
    GFCI Yes
    AFCI Optional
    RSD Optional
    Efficiency
    Max. Efficiency(PV to AC) (%) 98.2 98.4
    European Efficiency(PV to AC) (%) 97.2 97.9
    Max Efficiency (BAT to AC)(%) 98 98
    Battery RTE® Efficiency (%) 95 95
    Certifications
    Safety EMC IEC 62109-1&2, IEC 62040-1, IEC 62477-1
    Grid Certifications VDE 4105, IEC 61727/62116, AS 4777.2, EN 50549-1, C10/11,
    G98/G99/G100, CEI 0-21, NRS 097-2-1, RD 1699/661/647/413, UNE 217002
    General Data
    Dimensions(W*D*H) (mm) 530*212*550
    Weight (kg) 30
    Operation Temperature Range (℃)  -25~60 (>45 derating）
    Relative Humidity(%) 0~100
    Working Altitude (m) 4000 (>2000 derating)
    IP IP65
    Cooling Method Natural Cooling
    Display Bluetooth & APP + LED, LCD (Optional)
    Communication RS485/CAN (BMS), RS485, RS485 (for meter),
    Warranty DRM, 2*DI (1 RMO), 2*DO, Optional: WiFi/GPRS/LAN
